Specs - EcoFlow WAVE 3 Portable Air Conditioner
Dimensions
20.4×11.7×13.2 in (519×297×336 mm)
Net Weight
Approximately 33.7 lb (15.3 kg)
Cooling Capacity
6100BTU (1800W)
Heating Capacity
6800BTU (2000W)
Temperature Setting Range
60.8-86℉ (16-30℃)
Refrigerant/Amount
R290/0.25 lb (R290/112 g)
Air Volume
330m³/h
Rated Cooling Power (AC/DC)
690W/640W
Rated Heating Input Power (AC/DC)
645W/606W
Cooling Efficiency (AC/DC)
2.6/2.8
Heating Efficiency (AC/DC)
3.1/3.3
AC Input
100-240V~50/60 Hz, 820W Max
Add-on Battery Input
700W Max
Operating Temperature
41-122℉ (5-50℃)
IP Rating
IPX4
Noise Level
44-58 dB
Remote Control
App (Wi-Fi(2.4G, 5G), Bluetooth)
Run Time with EcoFlow Add-On Battery
2-8 hr
Specs - EcoFlow WAVE 3 Add-on Battery
Net Weight
Approximately 21.4 lb (9.7 kg)
Dimensions
20.3×11.1×4.4 in (516×281×111 mm)
Battery Capacity
1024Wh 51.2V 20Ah
Battery Chemistry
LFP
Cycle Life
80%+ capacity after 4000 cycles
Maximum Input Power
1000W Max
Automobile Auxiliary Power Outlet Charging Input
12V/24V,8A Max, 200W Max
Solar Input
11-60V, 13A Max, 400W Max
Maximum Output Power
858W Max
USB-A Output
5/9/12V, 2.4/2/1.5A, 18W Max
USB-C Output
5/9/12/15V⎓3A Max; 20V/28V⎓5A Max, 140W Max
Charge Temperature
32-113℉ (0-45℃)
Discharge Temperature
14-122℉ (-10-50℃)
IP Rating
IP65
Specs - Alternator Charger (800W)
Net Weight (lbs)
5.1lbs
Net Weight (kg)
2.3kg
Dimensions (Inches)
9.5×7.6×1.4 in
Dimensions (mm)
242×194×35 mm
Charging Mode
Input: 11V-31V, 76A Max.
Output: 40V-60V, 800W Max.
Reverse Charging Mode
Input: 40V-60V, 21A Max.
Output: 13.8V/27.6V, 800W Max.
Wi-Fi
Frequency: 2412MHz-2472MHz
Maximum output power: <20dBm
Bluetooth
Frequency: 2402MHz-2480MHz
Maximum output power: <10dBm
